By Chris Salomone
We show you how to build a modern, customizable picture wall in this step-by-step guide and video.

In this episode of Dwell Made, Chris Salomone of Foureyes Furniture builds and installs a minimalist picture wall that's ideal for displaying artwork and photographs.

Key Products:

¾" hardwood, softwood, or plywood of your choice

10" x 10" pre-cut mat board

Note: You can use any size boards, or cut them yourself. Try to stick with a consistent vertical dimensions.

Step 1: Cut Board to Length

Newsletter
Join the Daily Dose Mailing List

Get carefully curated content filled with inspiring homes from around the world, innovative new products, and the best in modern design

Dwell Made Presents: DIY Picture Wall - Photo 1 of 6 -

Start by cutting your piece of wood to the finished length you would like. I used 64", but you should pick a length that makes the most sense for your wall. You could do this with a table saw and a cross-cut sled, with a chop saw, or with a hand-held circular saw.

Step 2: Cut Board Into Strips

Dwell Made Presents: DIY Picture Wall - Photo 2 of 6 -

I cut my board into pieces that were all 1 ½" wide. Again, you can do this to whatever size you like design-wise, and cut as many pieces as are necessary for your wall. I needed four total for my design.

Step 3: Cut a Groove

Dwell Made Presents: DIY Picture Wall - Photo 3 of 6 -
Dwell Made Presents: DIY Picture Wall - Photo 4 of 6 -

Next, cut a grove into the top and bottom edge of each of your strips. To cut my grooves, I set my blade so that it was protruding about 1/8" above the table top of my table saw. Next, I set my fence so that the groove I cut would be located towards the back of my pieces, but not completely along the back. Once you’ve cut the groves, test fit a piece of your mat board. If it fits in, you’re done. If not, slightly adjust your fence to widen the grooves.

Step 4: Sand and Finish

I sanded my pieces with 80 grit, 120 grit, and finally 180 grit sand paper. Then I applied a coat of wipe-on Polyurethane finish. You could use just about any finish for this piece.

Step 5: Install

Dwell Made Presents: DIY Picture Wall - Photo 5 of 6 -

Spend some time planning and marking how you want your picture wall to be installed. Once you’re happy, use a level to make sure that the first (or bottom) piece is installed as level as you can get it. I used a couple of finish nails to attach my pieces to the wall. Once the first piece is in, use a couple of mat boards on either end to perfectly space the second piece—nail it to the wall and repeat until all pieces are installed.

Dwell Made Presents: DIY Picture Wall - Photo 6 of 6 -

For more projects like this, follow Dwell Made on Instagram and YouTube.
